  Product Name: Fixed Adjustable Mounting System MS-PV-SFA35
Download:   Right click the mouse "target save as" Download
Details

Fixed Adjustable Mounting System



Product Characteristics

  • To accommodate the subsidy cuts, investors need to guarantee and improve the photovoltaic power plant yield.
  • Improve 5%-7%+ power generation with only 2.5% increase in initial investment.
  • Monthly or seasonal angle adjustment; No electrical equipments, increased stability and reliability.
  • Can lay flat when installing, low installation cost, and faster assembly than fixed systems.
  • Larger tilt angle in winter, reduced snow coverage, prolonged working time.
  • Very low operation and maintenance cost, 1 person can adjust 2.5 MW per day.
  • Tilt angle can be any between 0~45 degrees.
  • Can address the unmet need of fixed systems, i.e. uneven angles.
  • Foundation requirements and costs same as fixed systems.
  • Fast production, same as fixed systems.



Product Specifications

Fixed Adjustable Mounting System

MS-PV-SFA

Model

MS-PV-SFA35

Array

Modules   Assembly Area

35m2

Modules   Assembly Arrangement

18 Modules

Modules   Reference

315W-1956x991x40mm

Power   Generation Capacity

5.67KW

Adjustable Angles

Adjustable   Angles Range

0~45°

Driving   Method

Manual Regulation

Adjustable   Frequency

As needed

Structure

Material

Hot Galvanized Steel

Max. Operating   Wind Load

22m/s

Max. Wind Load   at Stow Position

34m/s

Working   Temperature

-40°C-60°C

System Life

≥25years

Advantage

Improved   Power Generation

3%-8%

Certifications and   Warranties

Certifications

CE, ISO-9001

Warranty

10years



System   Characteristics

Multi-point   supporting

0°-45°adjustable

Low O&M cost

Increased stability and reliability

Less snow coverage in winter

Increased 3%-8% power generation

Also suitable for rooftop installation

Easy installation
